Looking for a high-quality, inexpensive H-frame press? This hydraulic pneumatic shop press maintains strength and accuracy with a fully-welded solid steel frame.
- 20-ton capacity.
- 19.25” working width.
- 7.5” cylinder stroke.
- Industrial-grade hydraulic components will provide years of reliable use.
- Adjustable table to fit a wide variety of applications.
- Includes pressure regulator and gauge.
- Rigid, electro-welded steel construction lets you work at full capacity with no worries about the machine flexing.
- Comes standard with a V-block set.
- Covered by a 1-year parts warranty and lifetime technical support by phone.
- Typically kept in stock for quick deliveries.
SPECIFICATIONS
| Item Number | HSP-20A |
|---|---|
| Piston Head Diameter | 2" |
| Movable Cylinder | Yes |
| Working Width | 19.25" |
| Maximum Capacity | 20 tons |
| Cylinder Stroke | 7.5" |
| Cylinder Diameter | 3" |
| Distance From Table To Ram | Min. 1.38" - Max. 35.91" |
| Power | Pneumatic / Manual |
| Shipping Weight | 300lbs |
| Shipping Dimensions (Inches) | 67x28x11 |
