TAPMATIC TAPPING HEAD 11915
Specifications
| Mount Type: Threaded | Shank Type: Threaded |
| Threaded Shank Size: 1-1/2-18 | Mount Size: None |
| Minimum Tap Capacity (Inch): 1/2 | Minimum Tap Capacity: 0.5 |
| Minimum Tap Capacity (mm): M10 | Maximum Aluminum Tap Capacity: 1.125 |
| Maximum Aluminum Tap Capacity (mm): M30 | Maximum Aluminum Tap Capacity (Inch): 1-1/8 |
| Maximum Mild Steel Tap Capacity (mm): M30 | Maximum Mild Steel Tap Capacity: 1.125 |
| Maximum Mild Steel Tap Capacity (Inch): 1-1/8 | Quick-change: No |
| Quick Change: No | Gear Ratio: 1.75:1 |
| Maximum RPM: 600.000 | Body Diameter (Decimal Inch): 4.175 |
| Body Diameter (mm): 105.000 | Body Diameter (Inch): 4-3/16 |
| Overall Length (Inch): 8-5/8 | Overall Length (Decimal Inch): 8.6250 |
| Overall Length (mm): 219.0000 | Arbors Included: No |
| Collets Included: No | Model Number: 90X II |
| Collet Compatibility: 26200 (J462); 26100 (J461) | Series: X |
