The Baileigh MWDC-550H is the 460V/3-phase version of Baileigh’s 5 HP wet dust collector, purpose-built for shops handling reactive or fine-particle metals where dry filtration falls short.
Its water-based separation captures sub-5-micron dust and polishing fumes, while 3,100 CFM of airflow and 15,151 FPM of velocity provide strong extraction at a quiet 75dB from 5 feet.
A 45L/70L capacity drum with an easy-view water level window and drain valve keeps maintenance straightforward. Built to support NFPA 660 combustible dust compliance, the MWDC-550H draws just 4.5A at 460V (10A breaker) and includes a 1-year parts warranty plus Baileigh Lifetime Technical Support.
Industries & Who It's For
Fabrication Shops
Typical work: Multi-material finishing where wet collection is required by the material — aluminum, titanium, stainless.
What they need: Needs a wet system matched to reactive or fire-sensitive materials.
Industries: Construction, Agriculture, Appliance Mfg, HVAC
Precision Machining
Typical work: Grinding and polishing dust extraction on reactive alloys in 460V facilities.
What they need: Needs multi-material-ready collection with 3,100+ CFM and fine-particle capture.
Industries: Aerospace, Medical Devices, Automotive, Electronics, Defense
Specialty MRO
Typical work: Multi-station dust collection on mixed and reactive materials.
What they need: Needs a system that reduces fire risk while keeping the shop clean.
Industries: Marine, Oil & Gas, Power Generation, Rail
Common Applications
- • Combustible / reactive metal dust collection: titanium, aluminum, copper, brass, and stainless — filters the smallest particles and reduces reactivity potential.
- • Sticky dust & fine sub-micron dust collection: supports NFPA 660 compliance and handles materials that would otherwise clog a dry filter.
- • 460V facilities: the lower amp draw (4.5A vs. 9A at 230V) simplifies electrical planning in higher-voltage shops.
Works with: Titanium, Aluminum, Copper, Brass, Stainless Steel
Warranty & Support: 1-year parts warranty plus Baileigh Lifetime Technical Support
Features
-
460V/3-phase operation draws just 4.5A full load amps, easing demand on shop electrical service
-
Wet separation captures sub-5-micron particles and polishing fumes that dry filters can miss
-
Helps reduce spark ignition and fire risk when collecting reactive or combustible metal dust
-
3,100 CFM airflow and 15,151 FPM velocity match Baileigh’s 230V wet collector for extraction power
-
Runs at just 75dB from 5 feet for a quieter shop floor
-
45L/70L capacity drum with easy-view water level window simplifies monitoring
-
10A recommended breaker size simplifies electrical planning for 460V shops
-
Supports a shop’s path to NFPA 660 combustible dust compliance
-
1-year parts warranty plus Baileigh Lifetime Technical Support round out the package
