BuildPro ALPHA 28 3.0 x 1.5 M Welding Table, Height-Adjustable Legs, Table Surface Height 750-1,100 mm (T28-3015XQ-B1)
BuildPro ALPHA 28 3.0 x 1.5 M (118.1" x 59.1") Welding Table with (6) T28-82407 Height-Adjustable 550-900 mm Legs for a Table Surface Height of 750-1,100 mm (29.5" - 43.3")
Tabletop size: 3,000 x 1,500 x 200 mm
Each plate of the table is made from a low alloy tool steel that’s tough enough for use in the mold-making industry. After surface grinding and machining, each plate is further enhanced with a QPQ nitriding process that improves hardness, corrosion resistance, and resistance to weld spatter.
Plates on the table can be repositioned, or removed as applications dictate; a patented plate locating system means the spacing of the holes are always within tolerance without the need for special re-calibration.
ALPHA 28 Table Specs:
- 5-sided Heavy Duty Modular Metric Welding Tables with 28 mm borehole
- Table Surface Height (mm): 750-1,100 (29.5" - 43.3")
- Table Capacity (kg): 6,000 (13,227 lbs.)
ALPHA 28 Table Accuracy
- Hole Diameter: 28 +.20/-.0 mm
- Hole Spacing: 100 ±0.05 mm
- Table Flatness: ±0.125 mm per 600 x 600 mm
- Plate Thickness: 25 ±0.06 mm
- Tabletop Finish : Nitrided (Heat-Treated) provides corrosion and weld spatter resistance for superior performance and wear
- Surface Hardness: 58-62 HRC
- Coefficient of Friction: 0.37
ALPHA 28 Top Plate:
- Material: P20 / tough low alloy tool steel
- Hardness: 58062 HRC
ALPHA 28 Side Plate:
- Material: Q345B
- Hardness: 50-55 HRC
Warranty: 1 year manufacturer's warranty
