Double Force Clamp, 39.5 Inch Capacity, 4-3/4 Inch Throat Depth

Bessey

$142.99
(No reviews yet) Write a Review
SKU:
SLV100M
UPC:
788502201605
Adding to cart… The item has been added

Double Force Clamp, 39.5 Inch Capacity, 4-3/4 Inch Throat Depth

The modular concept of the double force clamping system allows for an incredibly wide range of applications. There are 2 different rail cross sections available, SLV models are 27 x 13 mm (1-1/16 In. x 1/2 In.); the GSV model has a 30 x 15 mm (1-3/16 In. x 5/8 In.) profile for high clamping forces. Clamping widths range from 16 to 118 In. The rail end slide stops can be removed without tools. This allows for quick changes to the clamping set up. You can easily reverse the sliding arms for spreading or add extra sliding arms for clamping multiple pieces. Create custom assembly jigs for large assemblies quickly & easily. This versatility makes creating custom setups even for just one time use an economical prospect. SLV sliding arms available in 3 different styles, all with a 4-3/4 In. throat depth. GSV sliding arms all have spindles with sliding T-bar handles & are equipped with heavy duty MorPads for maximum clamping force. The standard GSV300M clamp sliding arms have a throat depth of 5-1/2 In. There are also 4-3/4 & 7-1/2 In. throat depth versions available. The clamping system's flexibility means numerous applications can be handled by the various combinations of rails and sliding arms. Clamp more with less using this unique BESSEY clamping.

FEATURES

Unique BESSEY MorPad tilts to 35° — easily removed for maintenance or replacement
Replacement arms, spindles and MorPads are available as well as many optional sliding arm assemblies
Rails are drawn, heat treated, tempered and quenched under rigid controls in BESSEY's own steel plant
Heat treated, high carbon acme threaded screw – tempered and quenched to give greater loading capacity and longer service life, spatter resistant
Drop forged, electro-galvanized steel sliding arm


SPECIFICATIONS

Acme Tools Brand Name
BESSEY
Acme Tools Part Number
SLV100M
Assembled Weight (lbs)
9.5
California Proposition 65 Warning Required
No
Clamp Type
Bar Clamp
Clamping Strength (lbs)
1450.0
Color / Finish
Zinc Plated Steel
Country of Origin
Germany
globalTradeItemNumber (GTIN)
00788502201605
Internal Supplier Part #
SLV100M
Internet Product Code (IPC)
54C5FDA6A8D
Jaw Width (in)
1.5
Manufacturer Warranty
Limited Life Time
Material
Steel
Maximum Opening (in)
39.5
Package Contents
1
Package Depth
47.0
Package Height
1.578
Package Weight
9.5
Package Weight (lbs)
9.5
Throat Depth (in)
4.75
