Grizzly G0920 - 22" Open-Ended Drum Sander

$2,120.00
(No reviews yet) Write a Review
SKU:
G0920
UPC:
690550318412

Grizzly G0920 22" Open-Ended Drum Sander

Need to sand wide panels or that live edge slab on your project list?

The open frame design of the G0920 22" Open-Ended Drum Sander allows you to sand workpieces up to 44" wide. Simply sand one half, turn the piece around and sand the other half.

The variable-speed conveyor can be adjusted between 0–20 feet per minute.

The digital depth gauge offers a precise reading of the distance between the table and the sanding drum.

The spring-tensioned sandpaper fasteners make changing belts quick and simple.

You’ll get precision results and long-lasting durability thanks to the 5" machined aluminum drum, heavy-duty enclosed stand, and easy conveyor belt tracking.

Like all Grizzly drum sanders, the G0920 comes with a 1-year warranty which covers parts and assures the unit is free from factory defects. (Consumables are not covered by the warranty.)

The G0920 manual was written by our U.S. based Technical Documentation Department and is packed with useful information.

The complete and easy-to-read manual provides full instructions on how to assemble and maintain your sander.

The Grizzly Customer Service and Technical Support Teams are U.S. based.

Parts and accessories for the sander are available online and shipped from the Grizzly parts warehouse in Springfield, MO.

SPECIFICATIONS:

  • Drum motor: 2 HP, 230V, single-phase, 7.5A
  • Feed motor: 50W, 1A
  • Maximum stock thickness: 5"
  • Minimum stock thickness: 1/4"
  • Maximum sanding width: 44"
  • Minimum sanding width: 2"
  • Minimum board length: 9"
  • Sandpaper speed: 2300 FPM
  • Conveyor feed rate: Variable, 0–20 FPM
  • Drum size: 5"
  • Dust port size: 4"
  • Sandpaper type: 3" width roll, plain backed
  • Footprint 23-1/2" x 32-1/2"
  • Overall dimensions 42-1/2" W x 43-1/2" D x 61" H
  • Approximate shipping weight: 341 lbs.

FEATURES:

  • Variable-speed conveyor
  • Digital thickness readout
  • Spring-loaded sanding belt tension/sandpaper
  • 4" Dust port with hose hook
  • Industrial-duty rubber conveyor belt
  • Push button circuit breaker for easy reset
