Knuth 2 kVA NeoSpark B 300 CNC Electric Discharge Machine 180558

Knuth

$74,900.00
(No reviews yet) Write a Review
SKU:
KN180558
Adding to cart… The item has been added

Description

The machines of the NeoSpark CNC series are among the most precise wire EDM machines with reciprocal wire guidance on the market. They offer excellent performance when machining electrically conductive materials in mold and tool making. The NeoSpark series is a popular choice for companies that specialize in additive manufacturing and want to separate the finished part from its base plate with high precision. High speed ​​wire cutting guarantees deformation-free and burr-free cutting of even the most delicate 3-D printed metal structures with the best surface quality.

Features

  • The NeoSpark CNC Electric Discharge Machine delivers excellent cutting performance and operating cost is extremely low
  • The cast-iron machine frame features a modern C-frame with T-base, multiple reinforcing ribs, precision-machined surfaces, and thermal stress-relief
  • Rigid linear guides and precision preloaded ballscrews on all axes ensure permanent mechanical precision
  • The IPC-based control system with servo drives is fine-tuned to the manufacturing process requirements and it is user-oriented and reliable
  • 2-step filtration system in the dielectric tank ensures uninterrupted operation and high machining quality
  • High-Speed Wire EDM – Cutting Technology for 3D Metal Printing
    • Compared to mechanical divisions, there is virtually no pressure on the component
    • Delicate structures can be machined without the risk of deformation or microcracking in the cut surface
    • Perfect balance between cutting accuracy and high cutting speed
    • Significantly more cost-efficient than conventional wire EDM
    • Long wire life ensures high productivity and minimal downtimes

Standard Equipment

  • IPC-based control system
  • Erosion wire 0.007"
  • Dielectric 22 lb.
  • Warning beacon
  • AC power stabilizer
  • Electronic hand-wheel
  • Generator
  • USB port
  • Ethernet
  • Standard wire guides
  • Dielectric tank with pump
  • Work lamp
  • Leveling plates and jacks
  • Central lubrication
  • Operating tools
  • Operator instructions

Specifications

  • Working Area
    • Workpiece weight (max.): 1,100 lbs.
    • Table dimensions: 24” x 17”
    • X-axis travel: 16”
    • Y axis travel: 12”
    • Z-axis travel: 10”
    • Workpiece, length x width x thickness (max.): 38” x 22” x 12”
    • Travel U / V-axis: 2.75 / 2.75”
    • Cutting angle (with guide): ± 10° / 3" null
  • CNC Control
    • Display size / type: 15" / LED null
    • Controlled axis: 4 null
    • Input increment (min.): 0.00004 in
  • Dielectric System
    • Dielectric, tank capacity: 48 gal
  • Feed
    • Rapid feed X / Y axis: 39”/min
  • Accuracies
    • Positioning accuracy X- / Y-axis: 0.0004”
    • Positioning accuracy U/V axis: 0.0008”
    • Repeatability X- / Y-axis: 0.0002”
    • Repeatability U / V axis: 0.0004”
    • Best surface roughness: 0.8 µm Ra
  • Drive Capacity
    • Total power consumption: 2 kVA
    • Motor rating Z-axis: 0.03 Hp
    • Motor rating X / Y axis: 0.2 Hp
    • Motor rating U / V axis: 0.03 Hp
  • Measures and Weights
    • Overall dimensions (length x width x height): 81” x 63” x 73”
    • Weight: 4,400 lbs.
