The Maksiwa CBC.PCR Automatic Edgebander delivers industrial-grade results with corner rounding for a flawless panel finish.
Equipped with high-frequency motors, pre-milling, buffing, and a cleaning agent spray system, it ensures a superior edge every time.
The XMELT glue pot system supports both EVA and PUR adhesives with efficient drainage, while the user-friendly PLC touchscreen allows full control of speed, temperature, and operations.
The automatic dust collector activates as needed, maintaining a clean and efficient workspace without manual operation.
| Manufacturer | Maksiwa |
|---|---|
| Condition | New |
| Features |
|
| Type | Edgebander |
|---|---|
| Automatic Feeding Speed | 18 ft/min |
| Panel Thickness Min/Max | 21/64" - 1-31/32" |
| Maximum Pre-Milling Height | 1" |
| Edgebanding Thickness | 0.0157" - 0.118" |
| Glue Pot Capacity | 3.3 lbs |
| Maximum Edgebanding Height | 2" |
| Minimum Panel Width | 3" |
| Minimum Panel Length | 7-7/8" |
| Extendable Panel Support Rail Length | 103" |
| Extension Table Maximum Width | 54" |
| Size of Dust Collector Ports | 6" |
| Minimum Dust Collection Requirements | 1236 CFM |
| Air Pressure Requirement | 14 SCFM @ 87PSI |
| Edgebanding Coil Support Diameter | 59" |
| Recommend Glue Temperature Range | 356°F - 410°F |
| Maximum Machine Dimensions (L x W x H) | 119" x 40-16/16" x 48.7/16" |
| Weight | 1411 lbs |
| Glue Type | Granulated Hot-Melt EVA / PUR |
| Electrical Information | 1 Phase 220V 30 Amps 60Hz |
| Electrical Requirement | 1 Phase 220V 40 Amps 60 Hz |
| Conveyer Motor | 60 Hz 1390 RPM .66 kw |
| Top/Bottom Trimmer HFM | 200 Hz 12,000 RPM .27kw |
| End/Corner Rounding Trimmer Motor | 200 Hz 12,000 RPM .27kw` |
| Front/Rear Pre-Milling HFM | 150 Hz 9000 RPM .75/.25Kw |
| Top Buffing Motor | 60 Hz 1680 RPM .11kw |
| Bottom Buffing Motor | 60 Hz 1680 RPM .11kw |
| Sound Rating | 80 dB |
| Eletrical specs | 1 Phase 220V 60Hz 30A |
| Feeder Speed | 18ft/min |
| Glue Temperature | 180° to 210° C |
| Glue Pot Type | Granulated Hot-Melt EVA / PUR |
| Workarea | 119" x 40" |
| End Trim | Pneumatic |
