Reelcraft 5650-OLP 3/8 x 50ft, 300 psi, Air / Water With Hose
Low Pressure Air/Water Reel
The Series 5005 reel is similar to the Series 4000 and 5000 except it handles hose lengths up to 50 feet. The Quiet Speed latch mechanism offers quiet operation combined with latch cam technology insuring longer latching life and trouble-free performance. Reels are all-steel construction and compact for applications with critical space requirements. The standard low pressure hose is for air or water service only. The basic reel without hose can be used for air, water or oil. Consult Reelcraft for other products and hoses. Compact, durable, versatile
Handles hose lengths up to 50'.
Low pressure hose reels furnished standard with PVC hose. Compressed air hoses should not be converted to oxygen service - may cause explosion when O2 mixes with fuel.
Specifications:
| Series: | 5005 |
| Grade: | Premium Duty |
| Drive: | Spring Retractable |
| Weight (lbs): | 36 |
| Hose I.D. (in): | 3/8" |
| Hose O.D. (in): | 0.6 |
| Hose Inlet Size (in): | 3/8 NPT(F) |
| Hose End (in): | 1/4 NPT(M) |
| Reel Outlet (in): | 1/4 NPT(F) |
| Hose Length (ft): | 50 |
| Hose Included: | Yes |
| Max Temperature (Fahrenheit): | 150 |
| Pressure (psi): | 300 |
| Primary Application: | Air |
| Secondary Application: | Water |
