Looking for the most reliable ¼” mild steel hydraulic shear on the market? You found it. With a Schneider NC controller and a steel plate frame, this shear was built for heavy production.


  • Can cut up to 10-foot wide metal sheets.
  • ¼” thick mild steel capacity.
  • Also makes quality cuts in lighter gauge materials.
  • 20 hp motor runs on 220-volt 3-phase power.
  • 20 to 30 strokes per minute—faster cycle times than many comparable shears.
  • Upper blade carriage rides in a 3-axis bearing housing.
  • Precision ground and hardened rail system offers unbeatable accuracy and longer blade life.
  • Touchscreen NC controller, made by Schneider, and foot pedal make this shear easy to operate.
  • Controller lets you program the backgauge to make the best use of each piece of steel.
  • You can program repeated sequences of pieces with different cut lengths.
  • Backgauge positioner rides on a screwball rail system and uses an encoder for accuracy.
  • Switch between 3 modes as needed:
    • Jog mode: Inching the blade down to the material.
    • Single cycle mode: One cut for one pedal push.
    • Automatic cycling mode: Continuously cutting for production runs.
  • Piece counter makes production runs more efficient.
  • Quick-change blade gap adjustment prevents the material from folding.
  • Rake angle adjustment improves the cut quality, reduces wear and tear on hydraulics, and prolongs blade life.
  • Multiple-sided high chromium blades (2 sides on top, 4 on bottom) can be flipped and sharpened many times, saving you money.
  • Fully welded plate steel frame maintains stability and helps prevent burring.
  • Covered by a 1-year parts warranty.
  • We stock replacement blades and parts so we can ship them out quickly.
  • Our team of representatives, all with hands-on experience, are here to provide lifetime technical support by phone.

You can add an optional sheet support system to this model. Please call us for details.



SPECIFICATIONS

Item Number SH-12003-HD
Back Gauge Length 17161
Shear Length 120"
Motor 20 hp
Thickness (SS) 1/4" (7 ga.)
Strokes Per Minute 20 – 30
Front Gauge Length 39.37"
Blade Angle 1/2° – 2° Adjustable
Blade Gap Adjustment Manual, Lever Acuated
Power 220V / 3-phase
Shipping Weight 15400lbs
Minimum Material Thickness 24ga
Shipping Dimensions (Inches) 166x75x85

* specifications subject to change without notice.
