SB1132 16" 3-Phase Parallelogram Jointer with Helical Cutterhead & DRO
High-capacity 16" industrial jointer equipped with efficient 3-phase power.
This top-of-the-line parallelogram jointer is the perfect choice for busy industrial shops that require quick turnarounds for large-scale projects. With 3-phase operation this machine is ready for continuous running in a fast-paced shop, and the 16" helical cutterhead with four rows of premium carbide inserts simplifies face jointing of boards that smaller machines can't handle.
An extra-long 100" precision-ground cast-iron table offers over eight feet of continuous support to true up long stock that would tip or bow on shorter jointers. It delivers superior mass and stability for square edges on massive boards, producing seamless, glue-ready results. A convenient, precisely calibrated digital readout guarantees table height accuracy for finely tuned cut depth settings.
Made in an ISO 9001 factory
FEATURES & BENEFITS:
- 3-Phase operation for consistent power
- 16" Wide helical cutterhead with 76 premium carbide inserts
- Smooth-adjusting parallelogram tables
- Massive precision-ground cast-iron table with total length of 100" x 16"
- Geared handwheel adjustment for precise infeed table settings
- Heavy-duty, precision-ground cast-iron fence w/rack and pinion adjustment
- Positive fence stops at 45°, 90°, and 135°
- Rabbeting table for production cutting rabbeting joints
- Digital readout in inch and metric for infeed table height
- Accessory column for mounting a power feeder (not included)
- Magnetic switch with thermal overload protection
- Knee-stop for quick, hands-free emergency shut off
SPECIFICATIONS:
- Motor: 7-1/2 HP, 220V/440V* (prewired 220V), 3-phase, 20A/10A
- Maximum width of cut: 16"
- Maximum depth of cut: 1/8"
- Maximum rabbeting depth: 3/4"
- Cutterhead diameter: 4"
- Cutterhead type: Helical
- Insert size and type: 15 x 15 x 2.5mm, indexable carbide
- Cutterhead speed: 5500 RPM
- Table size: 16" x 100"
- Fence size: 47-1/4" L x 6" H
- Minimum stock length: 18"
- Minimum stock thickness: 1/2"
- Dust port size: 6"
- Footprint: 55" x 27"
- Dimensions: 100" W x 46-1/2" D x 50" H
- Approximate shipping weight: 1449 lbs.
Meet every production goal with reliable power from the SB1132 16" 3-Phase Parallelogram Jointer.
Our U.S.-based Technical Documentation Department produces detailed owner's manuals and instruction sheets, empowering your team to optimize equipment performance and minimize downtime.
Comprehensive U.S.-Based Support:
Our experts provide a full range of support services including troubleshooting, maintenance tips, and parts sourcing. The 2-year warranty on the SB1132 safeguards your investment, offering peace of mind and ensuring long-term reliability.
Due to product size, this item must be delivered to a loading dock or unloaded with a forklift. Liftgate not available.
*This machine is prewired for 220V. We can rewire to 440V in a few days’ time for a fee. Please contact Grizzly Technical Support at (570) 546-9663 before placing your order.
