Specifications:
- Motor: 3HP, 220V, 13.8A, single-phase
- Spindle taper: R-8
- Spindle travel: 5"
- T-slots: 3 @ 26-1/2" centers, 5/8" wide
- Head ram travel: 12" (front to back)
- Head tilt: 45? left & right, 90? front & back
- Turret/column swivel: 360 degrees left/right
- Max. distance spindle to table: 15-7/8"
- Table travel (longitudinal): 29"
- Table travel (cross): 12"
- Table travel (vertical): 16"
- Table size: 9" x 49" x 3-3/4"
- Spindle speeds: 8, 80-2720 RPM
- Base footprint: 41" x 27"
- Approximate shipping weight: 2580 lbs.
- Please note: Due to this machine's weight, it cannot be delivered with our optional liftgate service
Features:
- 2-Axis DRO
- One-shot pump lubrication
- Auto stop with micro-adjustable stop
- Auto downfeed
- Longitudinal power feed
- Hardened and ground table surface
- Chrome-plated, precision-ground quill
- R-8 Spindle
- X- and Y-axis covers
- Forward and reverse spindle switch
- Halogen worklight
- Includes service tools and toolbox
