This lathe/mill combo is not your basic benchtop machine! The lathe cuts inch and metric threads, features 9 longitudinal feeds, and comes with a 4" three-jaw scroll chuck and 9-1/2" faceplate. The compound rest features a built-in vise and the cross slide conveniently doubles as a mill table. Meanwhile, the mill sports an adjustable head, coarse and fine downfeed controls, and comes with a 1/2" drill chuck with arbor. With the G4015Z, you get a lot of machine in a small package with all the features you need for just about any job!
LATHE SPECIFICATIONS:
- Swing over bed: 16-1/2"
- Swing over saddle: 11-1/2"
- Distance between centers: 19-3/16"
- Bed width: 5-1/2"
- Lathe spindle bore: 0.787" (20mm)
- Lathe spindle taper: MT#3
- Tailstock taper: MT#3
- Tailstock quill travel: 1-1/2"
- Cross slide travel: 4-1/2"
- Compound travel: 3"
- Maximum tool bit size: 1/2"
- Lathe spindle speeds: (7) 185–1455 RPM
- Leadscrew: 7/8" x 6 TPI
- Longitudinal feeds: (8) 0.0020–0.0069 in./rev.
- Inch thread range: (27) 8–120 TPI
- Metric thread range: (18) 0.2–3.0mm
MILL SPECIFICATIONS:
- Mill swing: 12"
- MIll spindle taper: MT#3
- Mill spindle travel: 3-1/2"
- Distance from spindle to table: 10"
- Distance from spindle to bed: 15-3/4"
- Mill head vertical travel: 3"
- Table dimensions: 6" W x 7-1/4" L x 1-1/2" Th
- T-slots: two at 7/16", 3.54" (90mm) on center
- Drawbar: 3/8-16 TPI, 10-3/4" L
- Mill spindle speeds: (14) 117–1300 RPM
- Maximum tool bit size: 1/2"
- Drilling capacity: 1/2" (steel)
MOTOR & BODY SPECIFICATIONS:
- Motor: 3/4 HP, 110V, single-phase 8.7A
- Footprint: 23" x 42"
- Dimensions: 42" W x 23" D x 35" H
- Approx. shipping weight: 475 lbs.
FEATURES:
- Cross slide doubles as a mill table
- Coarse and fine mill spindle downfeed
- 4-Way turret tool post
- Tailstock offsets 1/2"
- Built-in vise on compound rest
- Cuts inch and metric threads
INCLUDES:
- 4" Three-jaw scroll chuck
- 9-1/2" Faceplate
- 4-Way turret tool post
- 1/2" Drill chuck with arbor
- MT#3 chuck arbor
- Two MT#3 dead centers
- Set of change gears
- 5" Backplate
- Service tools
