Description
The latest addition to Grizzly’s vertical metal-cutting bandsaws offers affordable versatility not found on any saw in its class. Start with inverter motor speed control. 220V, single-phase goes in and 220V, 3-phase comes out, giving you variable speed control over the blade speed with just the turn of a dial. Blade changes are fast and easy with the quick-release blade feature. This combination allows you to cut any variety of materials (even wood!) and adjust for blade width, tooth pitch and speed on one machine!
Features
- Variable speed control
- Left and right table tilting control
- Upper and lower blade guides
- Rack and pinion adjustment on upper blade guide support
- Precision ground cast iron table
- Fully balanced cast iron wheels with rubber tires
- Quick release blade tension
- Steel guide blocks
- 2-1/2" universal dust port
- Includes rip fence and miter gauge
- Rip fence comes with: Right and left reading indicators, T-slots for quick change attachments, Dead lift quick release, Ball bearing slide, Solid lever lock
Specifications
- Motor: 1-1/4 HP, 220V, 3-phase, 1725 RPM, 4.8 Amps with single-phase inverter
- Required power source: 220V, single-phase, 60Hz
- Maximum cutting height: 10"
- Throat capacity: 13-1/2"
- Blade length: 108"
- Blade size range: 1/8" - 1"
- Included blade size: 108-1/8" x 3/8" x 6 TPI (similar to Grizzly model H9967 wood cutting blade)
- Blade speed: variable, 150 - 3000 FPM
- Table tilt: 45° right, 5° left
- Floor to table height: 38-1/2"
- Table size: 16" x 20" Overall dimensions: 72-1/2"H x 30"W x 30"D
- Approx. shipping weight: 277 lbs.
